Standard Fluids 7500™ Engineered Fluid: High-Temperature Heat Transfer for Critical Applications
SF 7500
Standard Fluids 7500™ Engineered Fluid: Precision Thermal Management for Extreme Conditions
SF 7500 fluid is a high-performance hydrofluoroether (HFE) engineered specifically for demanding thermal management applications requiring exceptional temperature stability. With a 128°C boiling point, this clear, colorless, and odorless fluid delivers reliable heat transfer performance across an extended temperature range from -100°C to 128°C.
Designed for semiconductor manufacturing, immersion cooling systems, and precision industrial processes, SF 7500 fluid combines ultra-low global warming potential (GWP of 90) with superior thermal properties. Its non-flammable nature and excellent dielectric strength make it the ideal choice for electronics cooling, reliability testing, and specialized cleaning applications where safety and performance cannot be compromised.
Features and Benefits
SF 7500 fluid is engineered for maximum performance and operational safety across critical thermal management applications.
- Exceptional Temperature Range: Operating range from -100°C to 128°C provides flexibility for diverse thermal management needs.
- Non-Flammability: With no flash point, SF 7500 fluid ensures safe operation in high-voltage electronics environments.
- Low Global Warming Potential: GWP of 90 enables facilities to meet environmental regulations. VOC exempt and EPA SNAP accepted.
- Superior Dielectric Properties: Dielectric strength of 35 kV (0.1″ gap) makes SF 7500 fluid ideal for direct contact with energized components.
- Excellent Materials Compatibility: Compatible with stainless steel, copper, aluminum, and hard polymers.
- Low Toxicity: Safe for workers and the environment.
Comprehensive Technical Specifications
SF 7500 fluid offers robust physical and chemical properties optimized for precision thermal management.
Key Physical and Chemical Properties:
- Physical State: Liquid
- Color: Colorless
- Odor: Odorless
- Composition: 3-ethoxy-1,1,1,2,3,4,4,5,5,6,6,6-dodecafluoro-2-trifluoromethyl-hexane (HFE-7500)
- CAS Number: 297730-93-9
- Boiling Point: 128°C
- Freeze Point: -100°C
- Flash Point: No flash point (non-flammable)
- Liquid Density: 1614 kg/m³
- Viscosity: 0.77 cSt
- Dielectric Strength: 35 kV (0.1″ gap)
- Global Warming Potential (GWP): 90
- Ozone Depletion Potential (ODP): 0
- VOC Status: Exempt
Versatile Applications Across Critical Industries
SF 7500 fluid is designed for demanding applications where thermal performance and safety are paramount.
- Semiconductor Heat Transfer: Ideal for cooling ion implanters, dry etchers, CVD/PVD tools, and other semiconductor manufacturing equipment.
- Immersion Cooling: Efficient thermal management for supercomputers, data centers (single and two-phase), and high-density power electronics.
- Industrial & Pharmaceutical: Precise temperature control for chemical reactors, freeze dryers, and synthesis equipment.*
- Reliability Testing: Effective fluid for thermal shock testing and hermetic seal testing.
- Precision Cleaning: Low surface tension enables precision cleaning and lubricant deposition.
Key Performance Characteristics and Advantages
SF 7500 fluid provides exceptional performance characteristics that set it apart in high-temperature thermal management applications.
- High Boiling Point: 128°C boiling point enables stable operation in extreme high-temperature applications.
- Wide Operating Range: Functions effectively from -100°C to 128°C for versatile thermal management solutions.
- Environmental Leadership: Ultra-low GWP of 90 helps meet corporate sustainability goals without sacrificing performance.
- Non-Conductive: Excellent dielectric properties allow safe direct contact with energized electronics.
- Materials Safe: Non-corrosive formulation compatible with common metals and engineered plastics.
Safety and Environmental Compliance
SF 7500 fluid is non-flammable and highly resistant to thermal breakdown during storage and use. In use, may form flammable/explosive vapor-air mixture under certain conditions.
Non-Hazardous Classification:
Low toxicity profile minimizes worker exposure concerns.
Regulatory Compliance:
TSCA compliant in the USA. EPA SNAP accepted for cleaning and cooling applications.
Recycle and Disposal:
Participate in our used fluid return program for safe and environmentally responsible disposal.
Safety Precautions:
Recommended handling procedures are provided in the Safety Data Sheet. Standard industrial hygiene practices should be observed.
For additional technical information and support, contact Standard Fluids’ technical service team:
Info@standardfluids.com | 888-322-1248
Frequently Asked Questions about SF 7500 fluid
SF 7500 fluid is a high-performance hydrofluoroether (HFE) engineered fluid. Specifically, it is composed of 3-ethoxy-1,1,1,2,3,4,4,5,5,6,6,6-dodecafluoro-2-trifluoromethyl-hexane and designed for critical heat transfer and specialized cleaning applications.
Primary applications include semiconductor heat transfer (ion implanters, dry etchers, CVD/PVD tools), immersion cooling for data centers and supercomputers, reliability testing, and precision cleaning applications.
SF 7500 fluid provides efficient heat transfer across a wide temperature range (-100°C to 128°C). Its ultra-low GWP of 90 reduces environmental impact while maintaining exceptional thermal performance. The high 128°C boiling point enables stable operation in extreme temperature applications.
SF 7500 fluid is non-flammable and has no flash point. This makes it safe for use in high-voltage electronics applications and environments where fire hazards must be eliminated.
SF 7500 fluid has minimal environmental impact with an ultra-low GWP of 90 and zero Ozone Depletion Potential (ODP). It is VOC exempt and EPA SNAP accepted for cleaning and cooling applications.
Yes, SF 7500 fluid is molecularly identical to discontinued 3M™ Novec™ 7500 (HFE-7500, CAS #297730-93-9), providing a seamless drop-in replacement path without equipment modification or revalidation.
*Not recommended for contact with human skin.
